Keychron QMK Wired keyboard shortcuts table - 60% Layout
For the Keychron QMK Wired Keyboard with a 60% layout, we've summarized the general and utility default function keys that can be accessed via key combinations, including changing light effects, resetting the keyboard, and other function key combinations. Below are the tables listing all the key combinations and functions they can access.
Light Effect
Keys | Function |
---|---|
fn + 5 | Backlight Brightness Decrease |
fn + 6 | Backlight Brightness Increase |
fn / fn1 + Q | Backlight Mode Next |
fn / fn1 + A | Backlight Mode Previous |
fn / fn1 + W | Backlight Brightness Increase (Backlight Turns On when Backlight is Off) |
fn / fn1 + S | Backlight Brightness Decrease (Backlight Turns Off when Brightness is at its Lowest) |
fn / fn1 + E | Backlight Hue Next |
fn / fn1 + D | Backlight Hue Previous |
fn / fn1 + R | Backlight Saturation Increase |
fn / fn1 + F | Backlight Saturation Decrease |
fn / fn1 + T | Backlight Speed Increase |
fn / fn1 + G | Backlight Speed Decrease |
fn / fn1 + tab | Turn On / Off the Backlight |
fn + backspace | Backlight Mode Next |
*For the Q60 keyboard, there is only a "fn" key.
Reset The Keyboard
Keys | Function |
---|---|
fn + J + Z (long press for 3s) | Reset the Keyboard |
Other Key Combinations
Keys | Function |
---|---|
fn / fn1 + esc | ` |
fn + K | Up Arrow |
fn + M | Left Arrow |
fn + , | Down Arrow |
fn + . | Right Arrow |
fn + P | Insert |
fn + [ | Page Up |
fn + ] | Home |
fn + ; | Page Down |
fn + ' | End |
fn + / | Delete |
fn + L | Screen Shot (Mac mode) Print (Windows mode) |
fn + N (Suitable for Q60) | N-key rollover |
*Except for "fn + N", the Q60 keyboard does not have access to other key combinations listed in the table above.
Multimedia and Function Keys
Keys | Function |
---|---|
fn + 1 | Screen Brightness Decrease |
fn + 2 | Screen Brightness Increase |
fn + 3 | Task View (Windows mode) Mission Control (Mac mode) |
fn + 4 | File Explorer (Windows mode) LaunchPad (Mac mode) |
fn + 7 | Previous |
fn + 8 | Play / Pause |
fn + 9 | Next |
fn + 0 | Mute |
fn + - | Volume Decrease |
fn + = | Volume Increase |
fn1 + 1 | F1 |
fn1 + 2 | F2 |
fn1 + 3 | F3 |
fn1 + 4 | F4 |
fn1 + 5 | F5 |
fn1 + 6 | F6 |
fn1 + 7 | F7 |
fn1 + 8 | F8 |
fn1 + 9 | F9 |
fn1 + 0 | F10 |
fn1 + - | F11 |
fn1 + = | F12 |
*For the Q60 keyboard, only function keys are available, such as pressing "fn" + "1" to access "F1".
Above are the default key combinations of Keychron QMK Wired Keyboard with a 60% layout. You can customize your key combinations on each layer and access more functions through the launcher software. Please click here and read "How to Use Different Layers to Set the Key Combinations" for details.
