Keychron QMK keyboard shortcuts table - 60% Layout
For Keychron QMK keyboards with 60% layout, we've summarized the general and utility default function keys that can be accessed via key combinations, including wireless connect, changing light effects, resetting the keyboard, and other function key combinations. Below are tables listing all the key combinations and functions they can access.
Wireless Connect
| Keys | Function |
|---|---|
| fn + Q | Select Bluetooth device #1 |
| fn + W | Select Bluetooth device #2 |
| fn + E | Select Bluetooth device #3 |
| fn + Q (long press for 3s) | Pair with Bluetooth device #1 |
| fn + W (long press for 3s) | Pair with Bluetooth device #2 |
| fn + E (long press for 3s) | Pair with Bluetooth device #3 |
| fn + R (long press for 3s) | Pair with 2.4GHz device (Only works on keyboards that support 2.4GHz mode) |
*For the K9 Pro, K12 Pro keyboard, using "fn1" with the keys listed above can change the wireless connection or pairing in the same way as "fn" + keys.
Light Effect
| Keys | Function |
|---|---|
| fn + 5 | Backlight Brightness Decrease |
| fn + 6 | Backlight Brightness Increase |
| fn + A | Backlight Mode Next |
| fn + Z | Backlight Mode Previous |
| fn + S | Backlight Brightness Increase (Backlight Turns On when Backlight is Off) |
| fn + X | Backlight Brightness Decrease (Backlight Turns Off when Brightness is at its Lowest) |
| fn + D | Backlight Hue Next |
| fn + C | Backlight Hue Previous |
| fn + F | Backlight Saturation Increase |
| fn + V | Backlight Saturation Decrease |
| fn + G | Backlight Speed Increase |
| fn + B | Backlight Speed Decrease |
| fn + Caps Lock fn + Control (Q60 Max) | Turn On / Off the Backlight |
| fn + Backspace (Q4 Pro, K12 Pro) | Backlight Mode Next |
*For the K9 Pro, K12 Pro keyboard, using "fn1" with the keys listed above can change the light effects in the same way as "fn" + keys, except for "fn" + "5" / "6".
Reset The Keyboard
| Keys | Function |
|---|---|
| fn1 + J + Z (long press for 4s) | Reset the Keyboard |
| fn + J + Z (long press for 4s)(Q60 Max) | Reset the Keyboard |
Other Key Combinations
| Keys | Function |
|---|---|
| fn1 + B (Suitable for V4 Max) | Check Battery (Only works in Bluetooth or 2.4G mode) RGB-Backlight Version Backlight Red = 0~30% Power Backlight Blue = 30%~70% Power Backlight Green = 70%~100% Power |
| fn + N | N-key rollover |
| fn / fn1 + Esc (Except Q60 Max) | ` |
| fn + K (V4 Max, Q4 Pro) fn + [ (Q60 Max) | Up Arrow |
| fn + M (V4 Max, Q4 Pro) fn + ; (Q60 Max) | Left Arrow |
| fn + , (V4 Max, Q4 Pro) fn + / (Q60 Max) | Down Arrow |
| fn + . (V4 Max, Q4 Pro) fn + ' (Q60 Max) | Right Arrow |
| fn + P (V4 Max, Q4 Pro) fn + \ (Q60 Max) | Insert |
| fn + L (V4 Max, Q4 Pro) fn + I (Q60 Max) | Screen Shot |
| fn + [ (V4 Max, Q4 Pro) fn + L (Q60 Max) | Page Up |
| fn + ] (V4 Max, Q4 Pro) fn + K (Q60 Max) | Home |
| fn + ; (V4 Max, Q4 Pro) fn + . (Q60 Max) | Page Down |
| fn + ' (V4 Max, Q4 Pro) fn + , (Q60 Max) | End |
| fn + backspace (V4 Max) fn + / (Q4 Pro) fn + ` (Q60 Max) | Delete |
| fn + P (Q60 Max) | Play / Pause |
| fn + Del (Q60 Max) | Backspace |
| fn + O (Q60 Max) | Scroll |
| fn + Tab (Q60 Max) | Caps Lock |
Multimedia and Function Keys
| Keys | Function |
|---|---|
| fn + 1 | Screen Brightness Decrease |
| fn + 2 | Screen Brightness Increase |
| fn + 3 | Task View (Windows mode) Mission Control (Mac mode) |
| fn + 4 | File Explorer (Windows mode) LaunchPad (Mac mode) |
| fn + 7 | Previous |
| fn + 8 | Play / Pause |
| fn + 9 | Next |
| fn + 0 | Mute |
| fn + - | Volume Decrease |
| fn + = | Volume Increase |
| fn1 + 1 | F1 |
| fn1 + 2 | F2 |
| fn1 + 3 | F3 |
| fn1 + 4 | F4 |
| fn1 + 5 | F5 |
| fn1 + 6 | F6 |
| fn1 + 7 | F7 |
| fn1 + 8 | F8 |
| fn1 + 9 | F9 |
| fn1 + 0 | F10 |
| fn1 + - | F11 |
| fn1 + = | F12 |
*For the Q60 Max keyboard, only function keys are available, such as pressing "fn" + "1" to access "F1".
Above are the default key combinations for Keychron QMK keyboard with a 60% layout. Some keyboard models may not be fully compatible; please refer to your keyboard’s manual for details. You can customize your key combinations on each layer and access more functions through the launcher software. Please click here and read "How to Use Different Layers to Set the Key Combinations" for details.
