Keychron QMK keyboard shortcuts table - 100%, 96%, 80%, 75% layout
For Keychron QMK keyboards with 100%, 96%, 80%, or 75% layouts, we've summarized the general and utility default function keys that can be accessed via key combinations, including wireless connect, changing light effects, resetting the keyboard, and other function key combinations. Below are tables listing all the key combinations and the functions they can access.
Wireless Connect
| Keys | Function |
|---|---|
| fn + 1 | Select Bluetooth device #1 |
| fn + 2 | Select Bluetooth device #2 |
| fn + 3 | Select Bluetooth device #3 |
| fn + 1 (long press for 3s) | Pair with Bluetooth device #1 |
| fn + 2 (long press for 3s) | Pair with Bluetooth device #2 |
| fn + 3 (long press for 3s) | Pair with Bluetooth device #3 |
| fn + 4 (long press for 3s) | Pair with 2.4GHz device (Only works on keyboards that support 2.4GHz mode） |
Light Effect
| Keys | Function |
|---|---|
| fn + F5 (Windows mode) | Backlight Brightness Decrease |
| fn + F6 (Windows mode) | Backlight Brightness Increase |
| fn + Q | Backlight Mode Next |
| fn + A | Backlight Mode Previous |
| fn + W fn + Knob Clockwise | Backlight Brightness Increase (Backlight Turns On when Backlight is Off) |
| fn + S fn + Knob Counterclockwise | Backlight Brightness Decrease (Backlight Turns Off when Brightness is at its Lowest) |
| fn + E | Backlight Hue Next |
| fn + D | Backlight Hue Previous |
| fn + R | Backlight Saturation Increase |
| fn + F | Backlight Saturation Decrease |
| fn + T | Backlight Speed Increase |
| fn + G | Backlight Speed Decrease |
| fn + Tab / fn + Light Effect Key / fn + Knob Press | Turn On / Off the Backlight |
Reset The Keyboard
| Keys | Function |
|---|---|
| fn + J + Z (long press for 3s) | Reset the Keyboard |
Other Key Combinations
| Keys | Function |
|---|---|
| fn + B | Check Battery (Only works in Bluetooth or 2.4G modes) RGB-Backlight Version Backlight Red = 0~30% Power Backlight Blue = 30%~70% Power Backlight Green = 70%~100% Power White-Backlight Version Two Rows Backlight off & the Other On = 0~30% Power One Row Backlight off & the Other On= 30%~70% Power All Backlight On = 70%~100% Power Non-Backlight Version Q Backlight Red= 0~30% Power Q W Backlight Red = 30%~70% Power Q W E Backlight Red = 70%~100% Power |
| fn + N | N-key rollover |
| fn + Caps Lock (C3 Pro Exclusive) | Switch Mac / Windows |
Multimedia and Function Keys
| Keys | Function |
|---|---|
| fn + F1 (Windows mode) | Screen Brightness Decrease |
| fn + F2 (Windows mode) | Screen Brightness Increase |
| fn + F3 (Windows mode) | Task View |
| fn + F4 (Windows mode) | File Explorer |
| fn + F7 (Windows mode) | Previous |
| fn + F8 (Windows mode) | Play / Pause |
| fn + F9 (Windows mode) | Next |
| fn + F10 (Windows mode) | Mute |
| fn + F11 (Windows mode) | Volume Decrease |
| fn + F12 (Windows mode) | Volume Increase |
| fn + F1 (Mac mode) | F1 |
| fn + F2 (Mac mode) | F2 |
| fn + F3 (Mac mode) | F3 |
| fn + F4 (Mac mode) | F4 |
| fn + F5 (Mac mode) | F5 |
| fn + F6 (Mac mode) | F6 |
| fn + F7 (Mac mode) | F7 |
| fn + F8 (Mac mode) | F8 |
| fn + F9 (Mac mode) | F9 |
| fn + F10 (Mac mode) | F10 |
| fn + F11 (Mac mode) | F11 |
| fn + F12 (Mac mode) | F12 |
Above are the default key combinations for Keychron QMK keyboards with 100%, 96%, 80%, and 75% layouts. Some keyboard models may not be fully compatible; please refer to your keyboard’s manual for details. You can customize your key combinations on each layer and access more functions through the launcher software. Please click here and read "How to Use Different Layers to Set the Key Combinations" for details.
